Key Specifications

• Manufacturer: General Electric
• Series: Mark VI Turbine Control
• I/O Type: Discrete Input/Output
• Input Channels: 48 (Contact Type)
• Output Channels: 24 (Relay Solenoid)
• FPGA Technology: Xilinx XC2S100
• Dimensions: 210 × 188 × 262mm
• Certification: UL/cUL Listed

Core Features & Applications

◼️ High-density I/O configuration for comprehensive turbine monitoring
◼️ Conformal coated PCB for harsh environment operation (-40°C to 85°C)
◼️ Real-time diagnostics through LED status indicators
◼️ Hot-swappable design for minimal downtime maintenance
◼️ Integrated with Mark VI’s TMR (Triple Modular Redundant) architecture

Typical Applications:

✓ Gas turbine speed control systems
✓ Steam turbine valve positioning
✓ Power plant emergency shutdown systems
✓ Rotating equipment vibration monitoring

Instant Support Available

Chat on WhatsApp


Email Inquiry

Technical Notes:

• Compatible with Mark VI Versions 5.0+
• Requires VCCC communication module
• Maximum load current: 2A per channel
• MTBF: 150,000 hours at 40°C
• RoHS compliant design
